1.3 Device window

The M&C offers a device window for each type of equipment it supports. Device windows can be launched by device details panel, device list. It shows all parameters read from the device and permits to alter each writable parameter. For clearance, the parameters are grouped to pages, you can switch between the pages using the tool-bar.

Functionality

• Drag and drop: Device window can be dragged from header and dropped anywhere in browser window.
• Resize device window: You can resize the window from every side expect top and top corners.
• Scroll buttons: If the toolbar menu is larger than the device window, the scroll button is displayed on the right or left side, depending on where the content is hidden.
• Duplicate window: The same device window can also be duplicated, which means it could be opened more the one time.
• Debug info: On mouse hover element details are displayed on bottom left side corner. It should be activated from 'User setting'
• Navigates through pages: Different type of page can be open from toolbar. Details of device window are described under 'Device window'.
