2.12.3.4.2 Dialogs

Add/edit TC channel dialog

• Trigger:

  • when you click on the "+" button on the top toolbar to create new or
  • an on pencil icon to edit TC channel in the menu column
  • The dialog title clearly indicates whether you are creating a new, editing an existing one, ensuring clarity in the action being performed.

• Fields:

  • Frequency 1: Primary receive frequency, floating point, MHz.
  • Frequency 2: Secondary receive frequency, floating point, MHz.
  • Polarization 1: This is an enumeration.
  • Polarization 2: This is an enumeration.
  • Comment: Free text describing the purpose of this dataset.
  • Default: Set TM channel as default.

• Actions:

  • Create/Save:
    • For new TM channel, this creates the TC channel with the provided details.
    • For existing TM channel, this saves modifications.
    • If an error occurs in the input fields, the button is deactivated.
  • Cancel: Closes the dialog without saving.

Modify TM channel attenuation

• Trigger: Click on the pencil outlined button in the row under attenuation

• Fields:

  • Select antenna: Drop-down to select antenna.
  • Attenuation 1: Transmit attenuation1, floating point, dB.
  • Attenuation 2: Transmit attenuation2, floating point, dB.

• Actions:

  • Save:
    • Saves modifications.
    • If an error occurs in the input fields, the button is deactivated.
  • Cancel: Closes the dialog without saving.

On delete confirmation dialog

• Trigger: Opens when you click the trash icon for an key from menu column.
• Content: Asks the user to confirm whether they want to delete the selected TC channel.
• Actions:
  • Yes: Deletes the TC channel permanently.
  • Cancel: Cancels the deletion action.
